Amp5
A professional standard for reliable, scalable, and turnkey destination charging systems.
The Game Changer
Amp5 offers everything a traditional charging box doesn’t:
- Reliable operation with redundant internet connections (LAN & 4G)
- Fraud protection through digital QR codes
- Freedom of choice with native OCPP compatibility
- Integrated surge protection and emergency stop
- Lightning-fast wired load balancing
- Self-healing system with automatic recovery
- Backup battery for alerts and unlocking the charging cable during power outages
- Over-the-air (OTA) software updates with uninterrupted charging sessions
- Support for Plug & Charge (ISO15118-20) and Vehicle-to-Grid (V2G) functionality
Flexibility. Scalability. Simplicity.
Discover how easy it is to install and expand Amp5.
A worry-free charging experience
Self-healing
Amp5 features centralized control that continuously performs self-diagnostics on functionality and connectivity. When needed, the system can automatically reboot at the processor level. This self-healing capability eliminates the need for costly on-site service technician visits.
Redundant connectivity
Amp5 features redundant internet connectivity via LAN and 4G.
A wired (2xLAN) two-way connection between all charging points ensures maximum reliability.
With Amp5, you are guaranteed an uninterrupted connection and a worry-free user experience.
Always up to date
No need to worry about system updates. All updates can be performed completely automatically (FOTA) and take less than 2 seconds, without interrupting ongoing charging sessions.
Lightning-fast load balancing
Protect the main fuse
With lightning-fast DLM, Amp5 adjusts the charging system's power usage in real-time to match the building's overall power consumption, ensuring you never exceed the capacity of your main fuse.
Charge more EVs
Amp5 supports 1/3-phase switching to optimize charging based on the type of electric vehicle. Phase switching also enables charging outlets to be used for engine preheaters.
Example with 63A: 2x11kW and 9x3.7kW
Smart charging
Charging optimization can be managed by an external charging service, such as based on departure time, or through local configuration using the desired method, such as first come, first served, round robin, or equal distribution.
Reduce power losses
With smart charging activated, charging sessions occur sequentially, allowing for higher charging power per session, thereby reducing energy losses.
Complete freedom with OCPP
OCPP is a communication standard between charging points and central charging services.
Unlike many chargers locked to proxy or cloud services, Amp5 is a native OCPP solution supporting both OCPP 1.6J and the latest OCPP 2.0.1.
Native OCPP means Amp5 communicates directly with central charging services, allowing you to easily switch providers in the future.
Future-Ready
OCPP 2.0.1 prepares you to embrace the new smart services of the future:
- Vehicle-to-Grid (V2G)
- Integration of Plug & Charge (ISO15118-20)
- Enhanced support for smart charging
- Improved hardware management
- Enhanced data security with encryption and certificates
Fraud protection & tailored messaging
Amp5 features a 4.3” color screen that helps prevent fraud with digital QR codes and encrypted RFID or phone tags.
Welcome your guests with a personalized message and display real-time data on the charging session.
Illuminate the parking experience
Did you know that parking areas are often where people feel the most unsafe?
That’s why Amp5 is available with integrated LED lighting to enhance both safety and comfort in your parking area.
Strict safety standards
Amp5 adheres to rigorous safety standards, including EN 61851-1 and EN-IEC 60947-2 Annex B, ensuring safe operation and protection against electrical faults. The system includes built-in Type B RCDs that automatically cut power in case of hazardous fault currents exceeding 30/6 mA (AC/DC).
Centralized Surge Protection
Amp5 protects both the charging system and connected EVs against lightning and power surges, which is also a legal requirement for public charging stations.
Emergency stop
Amp5 features a centralized emergency stop that can integrate with the property's existing systems. In case of a fire alarm, all charging sessions are halted.
Battery backup
With an integrated battery backup, system owners are notified of power outages, and users can safely end ongoing charging sessions to unlock the charging port.
Simple installation. Maximum reliability.
Amp5 is a complete and modular system with a simple and quality-assured assembly, ensuring a reliable and properly executed installation every time.
You avoid cable routing, groundworks, and the hassle of making different hardware components work together.
Amp5 Data sheet
| Max number of charging outlets | 54 per SmartHub¹ |
|---|---|
| Max number of simultaneous charging sessions | 30 per SmartHub¹ |
| Max incoming current | 63A |
| Max simultaneous charging power | 44kW |
| Max charging power per outlet | 22kW (3-phase), 7.4kW (1-phase) |
| Main fuse | 63A |
| Communication protocols | OCPP 1.6J / OCPP 2.0.1 / ISO15118-20 ready |
| Network connection | Teltonika RUT 901 with 4G SIM card & LAN. Wifi hotspot (only for configuration) |
| RF Technology | GSM, GPRS, EDGE, UMTS/HSPA+, LTE |
| RFID type | ISO/IEC 14443 Type A, 13.56 MHz Mifare |
| Current measurement | MID certification expected in H1 2025 |
| 24V input for external breaker | Yes |
| Static load balancing (fixed value) | Yes |
| Dynamic load balancing | Yes, via Internet or locally (Modbus TCP/RS-485) |
| Residual current device | Typ B per outlet (IEC60947-2) |
| Fuse | 32A per ChargePod (IEC60947-2) |
| Automatic circuit breaker | 63A, 32A B-characteristics |
| Battery backup (UPS) | Capacitor |
| Charging outlet type | Type 2, IEC 61851 |
| Display | TFT 480x272px, (HxDxW): 160 x 131 x 71 mm |
|---|---|
| Temperature range – operation | -30°C to +45°C air temperature |
| Temperature range – non-operation | -30°C to +65°C non-condensing |
| Material | Aluminium, at least 75% recycled (post-consumer scrap) |
| Color | Black (RAL 9011), powder-coated |
| Lock | EBR-lock ”Stockholm” |
| IP rating | IP44 |
| IK rating | IK10 |
| Color temperature 4000K, Power 8 W/m, Luminous flux 1050 lm/m | |
| Other | Customizable display content (logo, QR code, price, etc.). RCD test with magnetic sensor. User interaction via QR code, RFID, NFC. Lockable charging outlets. |
1 For more than 54 charging outlets, an additional SmartHub is added to Amp5.
